Pulse divider circuit - frequency divider, scaler or prescaler.
---------------------------------------------------------------
Electronic print for dividing pulses of tachometer or other devices. Intended for PLC.
Width 107mm for inserting in standard PCB holders. Supply 8 Volt to 30 Volt.
Two inputs, two outputs. The second one's are used to determine the rotating direction.
Open collector outputs with or without pull-up.
Input device will be fed by 5 volt and should be open collector type. Pull-up is on the circuit.
Standard is dividing by 256.
Second version of the above print:
Changes output level every X pulses, X being set in factory. Second output can be used for direction or as another divided value.
The device can be programmed as a versatile pulse generator, usefull for simulation, then reprogrammed in factory into divider.
Custom designed prints with specialised circuits for motor drive
---------------------------------------------------------------
Mainly custom designed following specifications
The device on the picture has 4 inputs, 4 outputs, and one 3 level output
Simple alternative to PLC 's
Contact us to discuss your needs
You can have an idea of the possibilities with the following check list
(check list for PLC)
