Electronic devices
Please note that we can make motors specifically adapted to inverters:
... extra motorised fan in case of the motor runs too slowly to permit cooling,
... adapted windings to avoid torque loss at high speeds,
...
Bearing with integrated electronic tachometer (see picture), (see connection).
Permits to have an electric motor with integrated tachometer.
Pulse divider circuit - frequency divider, scaler or prescaler.(see picture)
---------------------------------------------------------------
Electronic print for dividing pulses of the above tachometer or other devices. Intended for PLC.
Width 107mm for inserting in standard PCB holders. Supply 8 Volt to 30 Volt.
Two inputs, two outputs. The second one's are used to determine the rotating direction.
Open collector outputs with or without pull-up.
Input device will be fed by 5 volt and should be open collector type. Pull-up is on the circuit.
Standard is dividing by 256.
Second version of the above print:
Changes output level every X pulses, X being set in factory between 4 and 9999.
Second output can be used for direction or as another divided value.
The device can be programmed as a versatile pulse generator, usefull for simulation, then reprogrammed in factory into divider.
Custom designed prints with specialised circuits for motor drive: please contact us. (check list for PLC)
see also: Other components, special combination
